Always Evolving SSD
The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by the latest V-NAND technology and firmware optimization. It maximizes the potential of NVMe bandwidth for unbeatable computing. In capacities up to 2 TB, with reliability of up to 1,200 TBW.
Level up Performance
The 970 EVO Plus reaches sequential read/write speeds up to 3,500/3,300 MB/s, up to 53% faster than the 970 EVO. The latest V-NAND - which brings greater NAND performance and higher power efficiency - along with optimized firmware, a proven Phoenix controller, and Intelligent TurboWrite boost.
Design Flexibility
The next advancement in NVMe SSD. The 970 EVO Plus fits up to 2 TB onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung†s innovative technology empowers you with the capacity to do more and accomplish more.
Exceptional Endurance
The new standard in sustainable performance. Get up to 1,200 TBW with a 5-year limited warranty for lasting performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung’s quality.
Unparalleled Reliability
Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops.
Samsung Magician
Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.
Specifications:
- Application: Client PCs
- Interface: PCIe Gen 3.0 x 4, NVMe 1.3
- Dimension (W x H x D): 80.15 x 22.15 x 2.38 (mm)
- Weight: Max 8.0 g
- Storage Memory: Samsung V-NAND 3-bit MLC
- Controller: Samsung Phoenix Controller
- Cache Memory: Samsung 512 MB Low Power DDR4 SDRAM
- TRIM Support: Supported
- S.M.A.R.T Support: Supported
- GC (Garbage Collection): Auto Garbage Collection Algorithm
- Encryption Support: AES 256-bit Encryption (Class 0) TCG/Opal IEEE1667 (Encrypted drive)
- WWN Support: Not supported
- Device Sleep Mode Support: Yes
- Sequential Read: Up to 3,500 MB/s
- Sequential Write: Up to 3,300 MB/s
- Random Read (4 KB, QD32): Up to 480,000 IOPS
- Random Write (4 KB, QD32): Up to 550,000 IOPS
- Random Read (4 KB, QD1): Up to 19,000 IOPS
- Random Write (4 KB, QD1): Up to 60,000 IOPS
- Allowable Voltage: 3.3 V ± 5 % Allowable voltage
- Reliability (MTBF): 1.5 Million Hours Reliability (MTBF)
- Operating Temperature: 0 - 70 ℃ Operating Temperature
- Shock: 1,500 G & 0.5 ms (Half sine)
- Management SW: Magician Software for SSD management
